RP902
Bluetooth UHF RFID Pocket Reader
Over 12H with 75,000 scans|27dBm Power with 2M read range|IP65 Protect + 1.2M Drop
The RP902 is a compact, lightweight, and durable UHF RFID reader that maximizes your scanning efficiency and facilitates your operations at every task, including inventory check, cycle counting, asset management, and more!
-
Wireless
-
Bluetooth
-
1.2M
-
Retail
-
Hospitality
-
Healthcare
Via Bluetooth® 5.0, the portable reader is easily connected to your iOS, Android, or Windows mobile device at hand, satisfying your customer’s needs right away! The 75,000 scans with one single battery charge further empower in-store workers to a consistent inventory track over a long period. Combined with a changeable battery that can be fully charged in 2 hours, RP902 creates a seamless operation time in the application of the in-store retail, hospitality, healthcare, and pharmaceutical industries.
Features
• Lightweight and portable RFID reader in pocket size
• Perform 75,000 scans over 12 hours of operation time
• Fully-charged just within 2 hours with changeable Lithium battery
• Achieve 2-meter-long read range with strong sensoring signals
• Enterprise durability: 1.2M drop protection and IP65 sealing for ingress protection
• Bright and easy-to-read in 0.96” display screen
• Fast and easy pairing with iOS, Android, or Windows mobile device via Bluetooth® 5.0
Lightweight Reader in Durable Design
Well-fitting in your shirt pocket, the RP902 RFID reader has high mobility to solve your customer’s inquiry around the store environment. Coming with a sturdy design, the IP65 sealing for dust and water protection and the 1.2-meter drop to concrete provides you a durable design you can trust with.
|
|||||
|
|||||
106 g Delicate & Light |
IP65 Sealing |
1.2 m Drop Protection |
|||
Optimized Capture for Multiple RFID Tags
Our RP902 optimizes the RFID capture performance along with more tag reads per second and a longer read range. Workers achieve better productivity with the read of 75,000 tags over 12 hours. The 2-meter-long read rage and strong 27dBm signal on RP902 make stock picking, shipping, and delivery more precise, quickly, and accurately- creating a better customer experience.
|
|||||
75,000 Tags over 12 hours |
2 Meter Read Range |
27dBm Adjustable RF Power |
|||
Boost UHF RFID Read Performance |
|||||
Major Major RFID tags like EPC Global Class 1 Gen 2 and ISO 18000-6C compliant are supported to be read within the global frequency range between 865MHz and 928MHz (US/EU/JP/TW/CN). Integrated with a variety of software platforms, the RP902 lets retail staff check scanning results on the 0.96” display screen and then transmit the data to any devices to enhance asset management. |
|||||
0.96" Display Screen | |||||
|
||||
Flexible Pairing with Mobile Devices |
||||
|
||||
Bluetooth® 5.0 and USB cable support the snap-and-go pairing system on iOS, Android, or Windows mobile devices. Migrating to a new and versatile platform allows different associates to check the information at any time and any place! The smooth and immediate link to the RP902 brings in-store workers the comfort and ease to get ready with the next level of scanning. |
||||
Bluetooth 5.0 |
Extensive Pairing OS System |
|||
Specification
RFID
-
UHF
EPCglobal Class1 Gen2, ISO/IEC 18000-6C
865MHz ~ 928MHz (US/EU/JP/TW/CN)
UHF RFID Performance
-
Reading Distance
2-meter-long read
Communication
-
Bluetooth®
Bluetooth 5.0 (HID / SPP / BLE)
I/O Interfaces
- USB USB Type C * 1
Enclosure
- Dimension L 109 x W 51 x H 28 mm
- Weight 106 g
Durability
- Drop Specification 1.2M
- Sealing IP65
Environmental
- Operating temperature -10 to 50 °C
- Storage temperature -20 to 60 °C
-
Electrostatic Discharge
+/-8kV air discharge
+/-4kV contact discharge
Power Source
- Main battery 3.7V, 1150mAh, Lithium Battery (Changeable)
- Push Button 3 Buttons: Trigger / Function / Select
Software
- Software SDKs for Android, iOS & Windows configuration APP
Regulatory Approvals
- Types FCC, CE, NCC, SRRC, TELEC
What comes in the box
-
The standard package contents
■ RP902
■ USB cable
■ Battery
Accessories
-
Items
■ RP902 One-Slot Charging Cradle
■ Hand strap (PN#5500-900007G)
■ Power supply (PN#1010-900067G)
■ Neck Strap (PN#3210-900019G)
■ RFID tags/labels
