Android 12 with GMS Certified | Removable 5200mAh Battery (20 Working Hours) | IP67 Rating & 1.5m Drop

Android 12
4"
Keypad
Wi-Fi
13MP
IP67
1.5 m
GMS certified
Bluetooth
Retail
Logistics
Warehousing
Field Service
Manufacturing

As a reliable work companion, HT330 has been upgraded to the latest Android 12 OS system with GMS certification providing an intuitive and friendly interface to manage data effectively on a 4-inch screen. The removable 5200mAh Lithium-ion battery carries your task for over 20 hours, allowing a full shift to go on. Reaching IP67 enterprise protection and withstanding 1.5 drop makes HT330 a perfect tool to maximize data collection, management, and traceability in nearly every practice of retail, transportation& logistics, manufacturing, and more!

Features
• Android 12 OS with GMS certified
• Ergonomic one-handed operation
• Durable keypad with backlight: 32 keys with 2.5 million lifetime clicks
• 5200mAh battery for 20 hours of operation
• 1.5M drop-resistant housing (1.8M with bumper)
• IP67 protection against water and dust
• Support Bluetooth® 5.0
• Support MDM software and utilities such as MoboLink, SOTI, AirWatch, and 42Gears.

Real User Testimonials

Customer in Europe

We use this rugged handheld terminal at our European home decor brand, and it has significantly improved our operational...

Customer in Vietnam

In our Vietnamese warehouse operations, we rely on Unitech for its competitively priced and reliable barcode scanning to...

Latest Android 12 with GMS certified

This high-performance HT330 featuring a powerful 2D engine has upgraded to Android 12 OS to empower staff with an easy-scan, simple-check convenience. The GMS certification allows staff to access a set of pre-installed apps and services meant to boost productivity. HT330 is the best choice of optimal data collection terminal for the retail and warehousing field.


Android 12 Operation System	GMS Certification	Octa-Core 2GHz	1D / 2D Support

Extending Battery Capacity for All Day A larger battery capacity of HT330 means fewer battery replacements and longer operation time. The removable 5200mAh Lithium-ion battery supports 20 working hours, making it a suitable device for intensive scanning scenarios, like inventory checks. The 3GB RAM/32GB Flash memory storage undertake a high volume of data even after hours.

5200 mAh Li-ion Battery	20 Hours Operation time	3 GB RAM 32 GB Flash	295 g

Friendly Panel in Rugged Housing The one-hand terminal combines a 4-inch touchscreen with 32 keys physical keypad, providing a flexible interface to satisfy industries’ requirements. Water-resistant, dust-proof, and enduring drop to 1.5 m, HT330 can handle all demanding environments.

4-inch Display	32 Keys	IP67 Certification	One-Hand Operation

Rich and Reliable Wireless Connection HT330 lays a foundation of instant visibility into what's happening and being done under 2.4G+5GHz bandwidth. The Bluetooth® 5.0 improves the connectivity of related pairing devices, and the GPS function further tracks location more precisely.

Dual-Band Wi-Fi		Bluetooth® 5.0

Accessories Overview

Operation System

OS Android 12
GMS certified GMS certified
CPU Qcta-core 2GHz
Memory RAM 3GB
Flash 32GB
Security Supports Verified Boot
Languages support Multi-languages

Display

Screen Size 4”, WVGA 800 X 480, Backlight (450nits)
Touch Panel Multi-touch panel, gloves and wet hands supported

Buttons / Keypad

Buttons / Keypad Numeric (32 keys); number keys, function and direction keys with backlight

Camera

Camera Rear 13 MP Autofocus with flash

Indicator Type

Type LED, Speaker, Vibrator

Barcode Scanner

Default 2D Engine: Tilt Down 25 degree

Symbologies

1D Barcodes Support all major 1D barcodes
2D Barcodes Support all major 2D barcodes

RFID

HF RFID Optional: Frequency 13.56Mhz, ISO14443A/B,
ISO15693 standard, NFC, MIFARE, Felica

I/O Interfaces

USB USB 2.0 (Type-C)
OTG Yes, over USB Type-C
POGO PIN Pogo Pin Rear: Support Gun grip
Pogo Pin Bottom: Charging via cradle
Expansion Slot MicroSD memory card up to 256G
Audio Speaker: 1W output, 90 dB at 10cm
One microphone

Power Source

Main battery 3.85V 5200mAh Li-ION battery (removable),
Operating time : over 20 hours
(depending on the specific environment)

Communication

Bluetooth® Bluetooth 5.0
WLAN 802.11 a/b/g/n/ac/d/e/h/i/j/k/r/v, fast roaming, 2.4G+5GHz,
hotspot
GPS GPS/AGPS, GLONASS, BeiDou, Galileo

Software

MDM Software SOTI, Ivanti, Wavelink, 42Gears, and MoboLink

Enclosure

Dimensions ( W x H x D ) 185 mm x 70 mm x 23.8 mm
Weight 295g with battery

Durability

Drop Specification 1.5m / 1.8m (with boot case)
Sealing IP67
Tumble test Tumble 600 times (1.6 ft./0.5 m)

Environmental

Operating temperature -20°C to 60°C
Storage temperature - 40°C to 70°C (without battery)
Charging temperature 0°C to 45°C
Relative Humidity 5% ~ 95% (non-condensing)

Accessories

Accessories ■ 3.85V 5200mAh battery (PN#1400-900067G)
■ 5V/2A Adaptor with US plug for Terminal (PN#1010-900058G)
■ 5V/2A Adaptor with Universal plugs for Terminal (PN#1010-900067G)
■ USB Type C Cable (PN#1550-905919G)
■ Hand Strap (PN#386185G)
■ Boot Case(PN#3210-900035G)
■ Gun Grip (PN#5500-900100G)
■ Single Slot Charging Cradle (PN#5000-900098G)
■ Single Slot USB Cradle(PN#5000-900099G)
■ 4-slot Battery Charger (PN#5100-900035G)
■ 3 Pins Power Cord(US) for cradle (PN#1010-601551G)
■ 3 Pins Power Cord(EU) for cradle (PN#1550-602333G)
■ 3 Pins Power Cord(UK) for cradle (PN#1550-602689G)
■ Stylus with coil strap (PN#1979-900003G)
■ Glass Screen Protector (PN#401639G; PN#5400-900050G, 10pcs/ box)
■ Bracket only (without screws) (PN#386239G)
■ RP902 Bluetooth UHF RFID Pocket Reader (PN# RP902-33E8S0G (EU) / RP902-43A8S0G (US) / RP902-43F8S0G (JP)

What comes in the box

The basic package contents ■ HT330 Terminal
■ Battery
■ Hand Strap
■ USB Cable
■ Quick Start Guide

Regulatory Approvals

Regulatory Approvals CE, FCC, NCC, CCC, SRRC, VCCI, TELEC, RoHS, BQB, N-Mark, BSMI

Warranty

Hardware Warranty 12 months
Statement This product is warranted against defects in workmanship and materials for a period of twelve months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.
