MS822B

Wireless 2D Imager Scanner

100M operation range | IP52 and 1.5m drop | Up to 40 hours operation time

  • 2D

  • 1.5M

  • Wireless

  • Retail

  • Hospitality

Utilizing a megapixel 2D barcode scanning engine and the freedom of wireless  technology, the MS822B offers highly accurate performance and affordable price for the demands of a wide range of market applications, such as point-of-sale, loyalty, coupons checking, personal data identification, inventory control, and field service sectors.

Features

•  Support most 1D / 2D barcodes on mobile screens: up to 3 mil resolutions

•  Support 2.4G wireless technology

•  2.4G wireless transmission range up to 100m in the line of open sight.

•  Up to 40 hours of operation time per a fully charged battery

•  Rugged design: IP52 and 1.5 m drop spec

•  Offline inventory with 4 MB Memory flash

Multi-Interface Flexibility with 2.4G, Bluetooth, and USB-C



The MS822B wireless 2D scanner not only provides outstanding 1D and 2D barcode scanning capabilities but also excels in connectivity flexibility with support for 2.4G, Bluetooth, and USB-C interfaces. Whether maintaining a connection up to 100 meters away from the base with the 2.4G USB cradle receiver or choosing the best interface for specific tasks, this versatility enables users to customize their scanner setup to meet diverse operational demands, ensuring optimal efficiency in any environment.



Plug-And-Play Connectivity



The MS822B scanner is uniquely designed with a cradle featuring a built-in dongle, pre-paired before shipping for a plug-and-play experience right out of the box. This immediate connectivity extends to any mobile devices or computers, enhancing usability across multiple devices. Ideal for inventory control in retail and warehousing, the MS822B ensures efficient data management even when out of range. It automatically stores scanned barcodes and seamlessly transmits the data back to the host once within wireless coverage.





Long-Lasting Battery for All Day


With a long-lasting 2600 mAh removable battery, the MS822B can continue to capture barcodes for 40 hours, supporting all-day operation and featuring an easy battery-replaced design while reducing the total cost of ownership.





Compact but Durable



While sustaining a 1.5-meter drop to concrete, MS822B incorporated with IP42 rugged design for protection against dust and moisture. Moreover, the built-in long lifecycle trigger of 10 million times guarantees continuous productivity for the best reliability.




IP42
Certification		 1.5m
Drop Protection


ScanBridge Windows – The Best Companion Software to Your Unitech Scanners Coming Soon!



✔ Quick Setup, Easy Integration, and Auto Configuration: Effortlessly connect wireless scanners and automatically configure settings with ScanBridge, reducing initial setup time and enabling immediate use.



✔ Advanced Data Handling: Offers diverse output options, including Keyboard Wedge for keystroke data entry and Network Wedge for sending data directly to network services, facilitating efficient and adaptable data management.



✔ Customizable Profile Management: Create and manage tailored scanner profiles for specific applications, optimizing scanner performance across different scenarios and maximizing operational efficiency.





Learn more about ScanBridge: https://www.ute.com/en/products/detail/ScanBridge







Unitech Promises the Best After-Sales Support!



3-Year Warranty

Experience peace of mind with Unitech's comprehensive three-year warranty on the device, ensuring lasting reliability and service.







Especificación

System

  • Memory 4 MB
  • Key Trigger Key

Optical & Performance

  • Sensor 1280 x 800 pixels, CMOS Sensor
  • Aiming Element 625 nm LED
  • Illumination Color temperature 6000-6500 k
  • Ambient Light 0-100,000lux
  • Scan Rate 60fps/s
  • Skew Angle ±65°
  • Pitch Angle Sensor ±65°
  • Roll Angle 360°
  • Optical Resolution 3mil（code 39） 3mil（EAN13）
  • Depth of Field 13 mil EAN13 Near 50 mm Far 510 mm

Communication

  • Radio 2.4G Wireless
    Bluetooth V4.2 Class 2
  • Protocol 2.4G USB
    HID, BLE ,SPP
  • Wireless Coverage 2.4G: 100 m ( line of sight)
    Bluetooth: 10 m
  • Host Interface Supported USB Type C

Mechanical

  • Dimension 96.5 L x 72 W x 161 H (mm)
  • Weight 180g
  • Trigger Switch Life 1,000,000 times
  • Cradle Dimension 106 L x 80.5 W x 70 H (mm)

Functionality

  • Operation Mode Trigger Mode, Buffer Mode, Presentation Mode

Symbologies

  • 1D Barcodes 1D:Codabar、Code11、Code39、Code32、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code93、Code128、GS1-128、UPC-A、UPC-E、EAN 8、EAN 13、GS1 DataBar（RSS14）、GS1 DataBar Limited、GS1 DataBar Expanded、
  • 2D Barcodes 2D: PDF417、Micro PDF417、QR Code、Micro QR、Data Matrix、Aztec Code
  • Data Formatting Prefix, Suffix, Code ID

Electrical

  • Operation Voltage DC 5V
  • Current Consumption Operation mode:＜290mA , Standby mode:＜55mA
  • Indicator Buzzer LED light
  • Battery Type Lithium-ion
  • Battery Capacity 2600mAh 18650 battery
  • Battery Charging Time Fully charged in 6 hours
  • Operating Time Over 40 hours

Environmental

  • ESD Protection Functional after 4K Contact and 8K Air
  • Mechanical Shock 1.5m onto concrete (scanner only)
  • Operating Temperature -10°C to 50°C (14°F to 122°F)
  • Storage Temperature -20°C to 60°C
  • Relative Humidity 5% to 95% non-condensing
  • IP Rating IP52

Regulatory Approvals

  • Regulatory Approvals CE, FCC, BSMI, VCCI

What comes in the box

  • The standard package contents ■ MS822B scanner
    ■ Cradle integrated with 2.4G Dongle and cable

Warranty

  • Main Unit 1 Año
