The MS912 Plus Bluetooth companion scanner is the way to go for mobile scanning. Tiny but powerful, the MS912 Plus features simple pairing to any smartphone, tablet, or computer with a new aggressive scan engine.
Features
• Small and compact design
• Mobility application by wireless data collection and transmit
• Support HID and SPP connection
• High capacity battery with long life
• Premium performance: Processing up to 4mil resolution barcode readability.
• Build in 650 scans/sec high performance CCD module
• Easy to integrate with host (Smart phone, Tablet & Laptop)
• Easily toggle the iPhone/ iPad touch keyboard with iOS Hotkey function
Ultra-portable and durable
The MS912 Plus features the high-speed decoder paired with an aggressive scan engine which provides outstanding scanning performance up to 650 scans per second. MS912 Plus also delivers a high quality barcode scanning experience that can capture 1D barcode data with a 4 mil resolution and a scanning width up to 140mm. The scanner has capability to scan barcodes on the screen of mobile phone and it can automatically capture barcodes within its field of view in any lighting conditions from darkness to direct sunlight (100,000 lux). Furthermore, the MS912 Plus weighs in at just 30.2g and is about the size of a single pack of gum. Not only with an ultra-compact size, but also it has a 1.5 meter drop threshold. Combining high performance and compact design, MS912 Plus gives mobile worker many places to keep it conveniently and safely while on the go.
Easy pairing with wireless technology
The MS912 Plus provides the convenience of wireless technology with the simplicity of a single-button scanning design which makes barcode data collection simple, reliable for all users. With wireless communications, MS912Plus is easy to pair with your smart phone (including apple or android system) or tablet. Moreover, this device is available to facilitate a data transfer from scanner to computer via USB port and it delivers the flexibility with the 10 meters operating range that helps users to improve efficiency in mobile work place.
Extended Storage Capacity
Beyond its versatility, the MS912 Plus can be utilized with an auto mode that ensures no data is lost while it is out of range of the wireless signal, also upload the data to the back-end system with a simple setting, allowing users to complete their tasks without interruption. In addition, the MS912 series allows you to charge the internal Lithium-Ion battery by utilizing a standard USB port. With full compatibility to most every wireless enabled device, including Apple devices, it makes the MS912 Plus a best product for any mobile worker or business professional. There is no doubt that the compact MS912 Plus is an excellent auto data collection solution which is the smallest and smartest in its class.
TAA Compliant Barcode Scanners
![](/uploads/files/Product%20Feature%20Images/TAA/TAA.png)
Specification
System
- Memory 2MB
Optical & Performance
- Sensor Linear CMOS
- Aiming Element 625nm visible red LED
- Ambient Light 100,000 Lux (Sunlight)
- Scan Rate 650 Scans/ sec
-
Optical Resolution
4mil/ 0.1mm
140mm (13Mil Code39) - Printing Contrast Scale 30% Minimum
-
Depth of Field
4 Mil Code 39 : 40 ~ 65 mm
5 Mil Code 39 : 35 ~ 90 mm
10 Mil Code 39 : 35 ~ 195 mm
15 Mil Code 39 : 50 ~ 280 mm
13 Mil UPC/EAN: 35 ~ 230 mm
Communication
- Radio Bluetooth® 2.1+EDR
- Wireless Coverage 33 ft/ 10m (line of sight)
- Protocol BT HID, BT SPP, USB HID, USB VCP, Memory (MS912M Plus)
Mechanical
- Dimension H20*W30*L72mm
- Weight 30.2g
Symbologies
-
1D Barcodes
UPC-A/UPC-E, EAN-8/EAN-13, Industrial 2 of 5,
Codabar, Matrix 2 of 5, Code 11, Code 93, Code 32, Code 128, Standard Code 39, Full ASCII Code 39, Interleaved 2 of 5, China Postal Code, MSI Plessy Code, UK Plessy Code, EAN/UCC 128, Telepen Code, IATA Code, GS1 Databar
Electrical
- Operation Voltage 3.7VDC ± 5`00 scans (1 scan/ 5 secs, PAN connected)
- Current Consumption Operation mode:< 500uA (MS912 Plus)
- Battery Type 3.7V, 350mAh, Lithium Battery
- Battery Charging time 2 hours
- Operating Time 6000 scans
Environmental
- ESD Protection Functional after 4KV contact, 8KV Air discharge
- Mechanical Shock 1.5M
- Operating Temperature 0°C to 50°C
- Storage Temperature -20°C to 60°C
- Relative Humidity 0%~95%RH (Non-condensing)
Regulatory Approvals
-
Regulatory Approvals
EMC: FCC Part15C, CE
Safety Approval :WEEE, RoHS 2.0, IEC 62471, NCC, TELEC,VCCI, BSMI, TAA Compliant
What comes in the box
-
The standard package contents
■ MS912 Plus Scanner
■ USB cable (Mini USB)
■ Wrist Lanyard
Warranty
- Hardware Warranty 15 months
- Statement This product is warranted against defects in workmanship and materials for a period of fifteen months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.
