MS916

Wireless Pocket Laser Scanner

The MS916 is a 1D laser pocket scannerwith 1-inch OLED display allows enterprises to simply scan and check feedback of the scanned information in real time.

  • 1D Laser

  • 1"

  • Pocket Size

  • Wireless

  • IP42

  • 1.5 m

  • Bluetooth

  • Hospitality

  • Field Service

  • Healthcare

MS916 offers an user-friendly solution for streamlining productivity at customer-facing operations such as point of sale in retail stores, asset tracking in inventory management, as well as multiple applications in healthcare and medical business.



Features

• Stylish, lightweight, pocket-sized, wireless design
• Easy-to-use, user-friendly design with high-performance laser engine
• Supports all 1D barcode data, including GS1 data barcodes, at up to 4 mil resolution 104 scans/sec
• Bright, easy-to-read 1-inch OLED display
• Built-in Li-ion battery recharges through any standard USB connection
• Windows, Android and Apple compatible
• Easy to integrate with smart phones, tablets and laptops
• Rugged design that meets the 1.5 meter drop threshold; IP42-rated
• Bluetooth® 2.1+EDR , Class 2, & HID/SPP support

Real User Testimonials


Customer in the United States
Unitech’s products consistently meet our needs with reliable quality and excellent service. We use the MS916 pocke...

High Precision
​​​​​​​

The MS916 features a high-performance laser engine that gives it excellent scanning performance—up to 104 scans per second. The result is the ability to scan, capture and transmit even lower-quality barcodes at high resolution. Equipped with 650 nm visible laser diode, the MS916 can read and capture 1D barcode data—including GS1 data barcodes—at up to 4 mil resolution.

Portability and Durability



Designed specifically for mobile users and business professionals, the MS916 is a lightweight stylish design that slips easily into the average-sized pocket. Measuring just 36.9 x 95.9 x 21.1mm, it offers users a high degree of portability and versatility. IP42-rated, the solidly constructed MS916 has been built to withstand mechanical shock. It has been shown to pass the rigorous 1.5 meter drop test onto hard concrete, with the scanner’s functionality unaffected by the impact. Ruggedly designed, field-tested, durable, and reliable, it will work in temperatures ranging anywhere from 50°C all the way down to 0°C.

Smart Data Mapping Technology



The MS916 offers a user-friendly experience with three-button operation that is very easy to use, requiring no special training. Built-in a bright 1-inch OLED display, mobile workers can get feedback of the scanned information in real-time. This device is combined with Smart Data Mapping Technology (Lookup Table Function & Data View/Edit Function) that ensures data transmitted correctly and it is more flexibility to correct data immediately. In addition, through its wireless technology, the MS916 connects quickly and easily to virtually any laptop, tablet, or smart phone host—Windows, Android or Apple iOS. It can operate for distance up to 30M in open space.



Adding to its versatility, the MS916 also allows you to charge its built-in lithium-ion battery through any standard USB port. A 1-slot or 5-slot charging cradle is an optional accessory. The battery is fully charged within three hours. The unit comes standard with a strap and a micro USB-to-USB cable. Additionally, the MS916 has a flash memory storage capacity of 2MB (the equivalent of over 100,000 scans), making data loss extremely unlikely, even when it is out of range of the wireless signal. This allows mobile users to complete long tasks without interruption. At the rate of one scan every five seconds, the battery will last 8 hours on a single charge.

Versatility



The MS916 series has a wide range of potential applications:

．Retail and government workers can use it for access control, logistics, ticket and gaming applications, and other field service activities

．Pharmacy and medical store staff can employ it for medication inventory and warehousing

．It can be used for account management or as a personal identification device

．Courier services can employ it for proof of delivery functions

Precision Verification for Elderly Care Meal Services



The Unitech pocket scanner excels in extensive data verification and portable convenience, making it ideal for food factories that manage high-volume daily production and serve elderly hospitals and nursing homes. Its compact, pocket-sized design enhances the meal verification process, significantly increasing both accuracy and efficiency. Capable of processing 400,000 meals daily, this scanner ensures that each meal from the factories precisely matches the specific dietary needs of various care facilities, maintaining essential reliability.





Massive Data Verification

Support

Pocket Size

Design

Cost Performance

High


TAA Compliant Barcode Scanners

Specification

System

  • Display 1" OLED, 128 x 64
  • OS Proprietary, Connect to host with Windows, Android and iOS
  • Memory RAM 64 Kbytes
    Flash 2MB
  • Key 3 keys: Page up, Page down, Scan with power,on/off feature

Optical & Performance

  • Sensor Laser Engine
  • Aiming Element 650 nm visible laser diode
  • Scan Rate 104 scans/second
  • Skew Angle ±40 degrees from normal
  • Pitch Angle Sensor ±65 degrees from normal
  • Optical Resolution 4mil
  • Printing Contrast Scale minimum 25%
  • Depth of Field (DOF PCS=80%)
    Symbology | Density | Near | Far
    Code 128, 5 mils | 3.05 cm | 19.56 cm
    Code 39, 5 mils | 3.05 cm | 31.75 cm
    Code 39, 7.5 mils | 2.79 cm | 46.99 cm
    Code 128, 10 mils | 3.05 cm | 48.26 cm
    UPC, 13 mils | 4.06 cm | 68.58 cm
    Code 128, 15 mils | 2.54 cm | 74.93 cm
    Code 39, 20 mils | 3.56 cm | 132.08 cm
    Code 39, 55 mils | 8.64 cm | 254.00 cm
    Code 39, 100 mils | 60.96 cm | 518.16 cm

Communication

  • Radio Bluetooth® 2.1+EDR
  • Wireless Coverage Up to 30M (Open space)
  • Protocol Wireless SPP & HID profiles
  • Host Interface supported USB

Mechanical

  • Dimension 36.9mm x 95.9mm x 21.1mm
  • Weight 63g
  • Trigger Switch Life 10 million times

Functionality

  • Operation Mode Trigger mode, Pulse mode, Flash mode, Continuous
    Mode, Buffer mode

Symbologies

  • 1D Barcodes Code 39, Full ASCII Code39, Interleave 2 of 5, UPC A/E/E1, MSI, Codabar, Code 11, EAN8/13, Code 93, Code 128, EAN128, Code32, GS1 databar Code, Bookland EAN, Discreate 2 of 5, Chinese 2 of 5, ISBT 128, UCC Coupon Extended Code, Bookland 128
  • Data Formatting Prefix, Suffix, Code ID, Reformatting Date

Electrical

  • Operation Voltage DC 3V to 5V
  • Current Consumption Operation mode: <125mAh , Standby mode: < 39mAh
  • Battery Type Rechargeable Li-ion battery battery
  • Battery Capacity 680 mAh
  • Battery Charging time Fully charged in about 3 hours
  • Operating Time 8 hours at condition of 1 scan/5 sec

Environmental

  • ESD Protection Functional after 8K Contact and 12K Air
  • Mechanical Shock 1.5m onto concrete (scanner only)
  • Operating Temperature 0°C to 50°C
  • Storage Temperature -30°C to 70°C
  • Relative Humidity 95% non-condensing
  • IP Rating IP42

Accessories

  • Items ■ Wrist Lanyard (PN# 5500-900007G)
    ■ USB Type C Cable (PN#1550-905925GG)
    ■ 1-Slot Charging Cradle (optional / PN# 5100-900008G)

Regulatory Approvals

  • Regulatory Approvals CE, FCC, BSMI, VCCI, TAA Compliant

What comes in the box

  • The standard package contents ■ MS916 Scanner
    ■ Interface cable
    ■ Wrist Lanyard

Warranty

  • Hardware Warranty 15 months
  • Statement This product is warranted against defects in workmanship and materials for a period of fifteen months from the date of shipment. Accessories are warranted for three months to one year. Our different regions have varying warranty terms, and offer extended and comprehensive warranties, so please contact your local representative for more information.

Accessories

Wrist Lanyard

PN# 5500-900007G

MS916 1-slot Charging cradle (optional)

PN# 5100-900008G

Neck Lanyard

PN# 3210-900019G

Type C Cable

PN#1550-905925G
